Schneinder iPF K 40 modular surge arrester – 1 pole – 340V (A9L15686)
Rp497.402
Deskripsi
Spesifikasi
| range of product | Acti9 |
|---|---|
| Product name | Acti9 iPF K |
| Product or component type | Surge arrester |
| device short name | IPF K |
| Device application | Distribution |
| Standards | IEC 61643-11:2011 |
| Product certifications | EAC CE |
| Poles description | 1P |
| Remote signalling | Without |
| Surge arrester type | Electrical distribution network |
| Earthing system | IT 230 TN-C |
| surge arrester class type | Type 2 |
|---|---|
| Surge arrester technology | MOV |
| [Ue] rated operational voltage | 230 V AC (+/- 10 %) at 50/60 Hz |
| [In] nominal discharge current | Common mode: 15 kA (L/PE) Common mode: 15 kA (N/PE) |
| [Imax] maximum discharge current | Common mode: 40 kA L/PE |
| [Uc] maximum continuous operating voltage | Common mode: 340 V L/PE |
| Maximum [Up] voltage protection level | Common mode <1.5 kV type 2 L/PE |
| [Ut] temporary overvoltage | 337 V L/N 5 s withstand 442 V L/PE 5 s withstand 1200 V N/PE 200 ms withstand 1453 V L/PE 200 ms withstand |
| Disconnector device type | Associated circuit breaker iK60N 40 A curve C – Icu 6 kA Associated fuse gG 63 A – Icu 25 kA |
| Signalling circuit voltage | 0.25 A/250 V AC 50/60 Hz |
| Mounting mode | Clip-on (DIN rail) |
| 9 mm pitches | 2 |
| Height | 81 mm |
| Width | 18 mm |
| Depth | 69 mm |
| Product weight | 125 g |
| Colour | White (RAL 9003) |
| [Ipe] Ground residual current | 5 mA |
| Connections – terminals | Tunnel type terminal (top or bottom) 25 mm² rigid Tunnel type terminal (top or bottom) 16 mm² flexible Tunnel type terminal (top or bottom) 16 mm² flexible with ferrule |
| Wire stripping length | 11 mm |
| Tightening torque | 3.5 N.m |
| IK degree of protection | IK03 conforming to IEC 62262 |
|---|---|
| Relative humidity | 5…95 % |
| Operating altitude | 2000 m |
| Ambient air temperature for operation | -25…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2.2 cm |
| Package 1 Width | 7.4 cm |
| Package 1 Length | 8.8 cm |
| Package 1 Weight | 117.0 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 10.0 cm |
| Package 2 Width | 8.0 cm |
| Package 2 Length | 28.0 cm |
| Package 2 Weight | 1.478 kg |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 120 |
| Package 3 Height | 30.0 cm |
| Package 3 Width | 30.0 cm |
| Package 3 Length | 40.0 cm |
| Package 3 Weight | 15.267 kg |
| Warranty | 12 months |
|---|
